Model TAS: Stainless Steel Tube Adaptor

Stainless Steel Fitting Dimensions

Model Tube Adaptor
TAS
Tube ФD T, Thread Size Part No. A B H
1/8"10-32TAS 1/8 10-3223.413S11
1/8"1/8 NPTTAS 1/8 N1/826.213S11
1/8"1/4 NPTTAS 1/8 N1/429.513S14
5/32"10-32TAS 5/32 10-3225.415S11
5/32"1/8 NPTTAS 5/32 N1/828.215S11
5/32"1/4 NPT
3/16"1/8 NPTTAS 3/16 N1/828.215S11
3/16"1/4 NPTTAS 3/16 N1/431.515S14
1/4"10-32TAS 1/4 10-3228.418S11
1/4"1/8 NPTTAS 1/4 N1/831.218S11
1/4"1/4 NPTTAS 1/4 N1/434.518S14
1/4"3/8 NPTTAS 1/4 N3/835.518S18
5/16"1/8 NPTTAS 5/16 N1/834.221S11
5/16"1/4 NPTTAS 5/16 N1/437.521S14
5/16"3/8 NPTTAS 5/16 N3/838.521S18
3/8"1/8 NPTTAS 3/8 N1/834.221S11
3/8"1/4 NPTTAS 3/8 N1/437.521S14
3/8"3/8 NPTTAS 3/8 N3/838.521S18
3/8"1/2 NPTTAS 3/8 N1/24121S22
1/2"1/4 NPTTAS 1/2 N1/437.521S14
1/2"3/8 NPTTAS 1/2 N3/838.521S18
1/2"1/2 NPTTAS 1/2 N1/24121S22
4mmM5TAS 4 M525.415S11
4mm1/8 BSPTTAS 4 R1/828.215S11
4mm1/4 BSPTTAS 4 1/431.515S14
6mmM5TAS 6 M528.418S11
6mm1/8 BSPTTAS 6 R1/831.218S11
6mm1/4 BSPTTAS 6 R1/434.518S14
6mm3/8 BSPTTAS 6 R3/835.518S18
8mm1/8 BSPTTAS 8 R1/834.221S11
8mm1/4 BSPTTAS 8 R1/437.521S14
8mm3/8 BSPTTAS 8 R3/838.521S18
8mm1/2 BSPTTAS 8 R1/24121S22
10mm1/8 BSPTTAS 10 R1/834.221S11
10mm1/4 BSPTTAS 10 R1/437.521S14
10mm3/8 BSPTTAS 10 R3/838.521S18
10mm1/2 BSPTTAS 10 R1/24121S22
12mm1/4 BSPTTAS 12 R1/437.521S14
12mm3/8 BSPTTAS 12 R3/838.521S18
12mm1/2 BSPTTAS 12 R1/24121S22
Dimensions for Reference Use Only: Imperial fittings in mm, Metric fittings in mm, U.S.O.

Link to Stainless Steel Fittings Specification Guide
